Thermal CTP Plate(Process-less)

Thermal CTP Plate(Process-less)

Download template

Product Details

Application
Lecai thermal CTP plates are able to meet a wide variety ofrequirements for high-end commercial color printing and newspaper printing.It has the advantages of speedy plate-makinggood tolerance level,precise halftone dot reproduction,goodink balance and long run-length.Process less CTP plates arenew generation of environmentally friendly printing product,suitable for thermal CTP plate-making machine dedicated plate.It can be printed directly in the machine after exposure withoutany washing processing steps.

Characteristic
1.High quality aluminum,composite grain and long run-length.
2.Capable of bright room operation.
3.High resolution and precise halftone dot reproduction.
4.Good development tolerance and convenient operation.
5.Environmental and pollution free.6.Faster exposure.

General Information
Plate Type Process-less Thermal CTP Plate
Application High quality commercial and newspaper printing
Substrate Electro chemically Grained and Cathodic lithographic Aluminum
Aluminum alloy Standard 1050 and 1060 Alloy
Coating R sensitive,negative acting
Gauge 0.15,0.20,0.25,0.30,0.40(mm)
Maximum short grain width 1380mm
Length of Run Ordinary Ink:80,000 to 100,000 impressions

Exposing
Plate setters

Kodak: Trendsetter/Lotem/Magnus Fuji: Javelin T900OHS
Heidelberg: Top setter/Supra setter
Luscher: Xpose Plate setter
Screen: PT-R Creo:Scitex

Exposure energy 130-150mJ/cm²
Spectral Sensitivity 800-850 nm -Peaks830nm
Resolution 1-99%at 300 LPI
FM capability 20 micron stochastic
Image color Light blue

Storage and handling
Safelight Handle under yellow safelight (UV free)
Shelf Life 6months under recommended storage conditions
Storage and handling stored in a cool and dry environment,away from excessive cold,
heat and humidity.
