Lecai Thermal UV-CTP plates are fast-exposing plates designed for UV links.They are also compatible with conventional inks, and when using standard ink, development is fast and the run length will be significantly extended. These plates are ideal for high-end commercial color printing and newspaper printing, offering excellent performance and durability.
Product Details
Application
Lecai Thermal UV-CTP plates are fast-exposing plates designed for UV links.They are also compatible with conventional inks, and when using standard ink, development is fast and the run length will be significantly extended. These plates are ideal for high-end commercial color printing and newspaper printing, offering excellent performance and durability.
Characteristic
1.UV ink resistance
2. High quality aluminum, composite grain and long run-length.
3. Capable of bright room operation.
4. High resolution and precise halftone dot reproduction.
5.Good development tolerance and convenient operation.
General Information | |
Plate Type | Thermal CTP Plate(Double Layer) |
Application | High grade commercial and newspaper printing |
Substrate | Electro chemically Grained and Cathodic lithographic Aluminum |
Aluminum alloy | Standard 1050 and 1060 Alloy |
Coating | Two-layer system,IR sensitive,positive acting |
Gauge | 0.15,0.20,0.25,0.30,0.40(mm) |
Maximum short grain width | 1380 mm |
Length of Run | Ordinary Ink:100,000 to 150,000 impressions UV Ink:30,000 to 50,000 impressions |
Exposing | |
Plate setters | Kodak: Trendsetter/Lotem/Magnus Fuji: Javelin T9000HS Heidelberg: Top setter/Supra setter Luscher: Xpose Plate setter Screen: PT-R Creo:Scitex |
Exposure energ |
100-120 mJ/cm² |
Spectral Sensitivity | 800-850 nm -Peaks |
Resolution | 1-99%at 200 LPI |
FM capability | 20 micron stochastic |
Image color | Blue Green to Pale Green |
Developing | |
Processor | All the kind Brands. |
Developer | Kodak Gold Star orour Lecai DP-Ⅱ developer |
Processing temperature | 23℃+/-2℃ |
Developing time | 22+/-5 sec |
DynamicSupplement | 80-120 ml/m² |
Storage and handling | |
Safelight | Daylight handling |
Shelf Life | 18 months under recommended storage conditions |
Storage and handling | stored in a cool and dry environment,away from excessive cold, heat and humidity. |
